The Setup

When Robert Maxfield first learned about his customer’s desire to create a modern national data operations center, the customer already had some idea of how they would want it to be built out. The original idea included a ton of expensive video hardware that would be able to drive video output cards capable of running several high-definition TVs.

This solution had several shortcomings. The first issue was that it was going to be very expensive. Secondly, the timeline to procure the hardware and configure it was very lengthy. Finally, even after all the expense, the system would not be very flexible if new applications needed to be added in the future. Enter, Robert Maxfield from WachsField Technologies.

Maxfield, a seasoned system integrator, had used ThinManager on previous projects with great success. He knew the end result his customer was seeking could be achieved at a lower cost. He also knew that if they ever wanted to easily scale up from the initial design, they would need a better plan than just continuing to purchase overpriced video display and routing components. After discussing the new plan with the customer, WachsField Technologies developed an alternative design leveraging ThinManager and Arista thin client hardware.

WachsField was tasked with creating an operations center with ten 60’ high-definition TVs that would be used as monitors. The customer had thirteen different applications that would need monitoring including GE IFIX HMI, Proficy Web Trending, Call Center Applications, GSA system, work order programs, mapping software, IP cameras and more.

The Deployment

Using ThinManager, WachsField Technologies was able to configure secure connections to the company’s datacenter to provide displays to all ten 60” monitors. “Using ThinManager’s MultiSession, MultiMonitor and Tiling features, we were able to divide the screens in various configurations according to the client’s needs,” stated Maxfield. “Each station at the NOC was outfitted with a laptop and an iPad. The iPads are running ThinManager iTMC and are able to Shadow the larger screens—bringing pertinent data right to the station. This also allows for the NOC staff to modify the layouts on the larger overall screens.”

WachsField also deployed two additional ThinManager features to enhance security and improve the end user experience. The first was WinTMC. Just like iTMC can be installed on iPads, WinTMC can be installed on PC workstations and laptops. This allows ThinManager to centrally manage and deploy applications to those devices in the same way they are deployed to thin clients. In this case, the end users can easily switch between applications local to their laptop workstations and those being delivered by ThinManager.

The second was AppLink. This is a simple ThinManager setting that removes access to the desktop when deploying applications to thin clients. By using this option on the thin clients that drive the large operations center displays, only the required applications are displayed. This reduces the potential for end user error and keeps the NOC staff focused on their jobs.

“The operations center is now running day in and day out utilizing ThinManager. ThinManager’s technology saved the client thousands of dollars and allows for extreme flexibility such as adding new IP cameras feeds as new cameras are installed and new stations come online,” Maxfield explained. “We will continue to use ThinManager whenever we can. Our customer decided it was the best solution for their national operations center based on flexibility, scalability, cost and simplicity. This project was a success on all those points.”

Project Overview

ThinManager deployment to expand visualization for new National Operations Center:

• ThinManager Redundant servers
• 4 – Arista BoxPC 240 thin clients, unlimited client connections
• 10 – 60” high-definition TV monitors

Fit for ThinManager:

[...]
